· The inside of the machine body is arranged with W-type A-type composite rib plate, which has good bending and torsion resistance and adopts long-span linear rail structure, so the table can run with stable accuracy for a long time.

· The table adopts double shin plates and densely covered tic-tac-toe rib plate to reduce its own deformation and improve its bearing and seismic resistance.

· Highly rigid one-piece casting column and beam structure with large contact area and precision manual scraping, as well as stable structure and good precision maintenance.

· The column adopts UK-flag shaped rib plates and large sectional beam, and the guide rail adopts a stepped structure, which effectively inhibits the machine tools from tilting forward and ensures the stability of processing.

· The sliding saddle adopts a configuration of three upper and two lower sliders, and the ram adopts an optimized rectangular cross section, which can achieve strong cutting and small vibration deformation; the ram can be configured with four linear rails on the left, right, front, and back with four-sided constraints, making heavy cutting more stable.

· The 3 axes adopts high-precision and large-diameter grinding ball screw to load axial pretension, so that the rigidity and stability of the transmission system can be ensured.
